UNS S32205 is a two-phase, ferritic, austenitic stainless steel alloyed with chromium of 22%, molybdenum S32205 of 3%, and nickel of 5% to 6%. It is the most popular grade of duplex stainless steel and has a yield strength that is twice as high as that of austenitic stainless steel standard grades. It has excellent performance in the majority of caustic environments, high resistance to pitting and crevice corrosion, and good weldability.
Duplex Steel UNS S32205 flanges exhibit superior corrosion resistance and resistance to localized corrosion like intergranular, crevice and pitting corrosion. UNS S32205 Duplex Steel flanges have superior chloride stress corrosion cracking resistance, high strength and can withstand the brackish or saltwater impact, and high surface toughness. These flanges are designed to resist crevice, intergranular, and pitting corrosion effectively and can also withstand chloride stress corrosion cracking. ASTM A182 Duplex Steel UNS S32205 flanges are designed to perform effectively at temperatures ranging from -50°F to 1200°F, making them a versatile option for both industrial and domestic projects. Additionally, Duplex S32205 flanges are essential in chemical processing industries for handling waste and byproducts. Duplex S32205 grade offers enhanced durability compared to other grades, with excellent welding and forming properties. The flanges are made with a chemical composition rich in nickel, chromium, and carbon, along with silicon, manganese, and phosphorus. They feature a minimum tensile strength of 116,000 psi (800 MPa) and a yield strength of 80,000 psi (550 MPa), making them suitable for high-temperature applications.
We are suppliers of ASME SA182 Duplex Steel UNS S32205 Weld Neck Flanges to sea water and power generation equipment as their smooth surfaces can endure a temperature up to 600 ° F besides promoting excellent flow characteristics. Duplex 2205 Flanges are made up of a dual nature steel that has austenitic and ferritic microstructures in its metallurgy. The material is corrosion resistant to chloride stress. It is used at corrosive environments. JN Alloy produces flanges in 2205 material and supply them in large quantities. There are classes ranging from 150 to 2500 and PN6 through PN64 in 2205 flanges. We are leading Duplex 2205 Flanges Supplier in India. The classes correspond to the pressure capacities of the flanges. The different varieties of the flanges include the Duplex UNS S32205 Orifice Flange which is the most commonly used duplex orifice flange. The applications of the flanges vary based on the requirement. The ANSI B16.5 UNS S31803 Duplex Steel Blind Flange is used to close a pipe and it ranges from ½ inches to 48 inches in nominal bore size as determined by the standard.
We have been ushering new stratagems to be quicker in delivering consignments. As exporters, our Duplex Steel DIN 1.4462 Socket Weld Flanges are competent to convey gases up to 600 psi, packaged and shipped to the nearest port for your convenience. A coordination between our production and sales team garner us to supply worldwide. Also We offer wide range of Duplex Steel ASTM A182 Flanges such as Duplex 2205 Slip On Flanges, Duplex Steel S32205 Weld Neck Flanges, Duplex F51 Socket Weld Flanges, Gr. F52 Duplex Blind Flanges, Duplex Steel F60 Orifice Flanges, Duplex Steel S32205 Spectacle Blind Flanges, Duplex Steel F60 Screwed / Threaded Flanges, Duplex Steel F60 Reducing Flanges, Duplex 2205 Ring Type Joint Flanges (RTJ) etc.
Dimension Std. | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
Standards | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
Specification | ASTM A182 / ASME SA182 |
Size | ½” NB – 48″ NB |
Class | 150#, 300#, 600#, 900#, 1500#, 2500# , etc |
Pressure | DIN PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160, etc |
Werkstoff Nr | 1.4462 |
Threaded Flanges | Threaded Flanges are also known as screwed flange, and it is having a thread inside the flange bore which fits on the pipe with matching male thread on the pipe. |
Socket-Weld Flanges | Socket-Weld Flanges has a female socket in which pipe is fitted. Fillet welding is done from outside on the pipe. |
Slip-On Flanges | Slip-On flange has a hole with matching outside diameter of pipe from which pipe can pass. The flange is placed on pipe and fillet welded from both inside and outside. |
Lap Joint Flanges | Lap flange is having two components, a stub end, and a loose backing flange. Stub end is butt welded to the pipe and Backing flange freely move over the pipe. |
Weld Neck Flanges | Weld neck flange are most widely used flanged in process piping. It gives the highest level of joint integrity due to Butt-welded with a pipe. |
Blind Flanges | The blind flange is a blank disc with bolt hole. These types of flanges are used with another type of flange to isolate the piping system |
Screwed Flange | 3Screwed Flange is used to connect other components in non-critical applications, low-pressure in which no welding is required. |
Reducing Flange | A reducing flange consists of a flange with one specific diameter having different bore and smaller diameter. It s used to change the diameters in piping system. |
Forged Flange | They are designed by using corrosion free substance and using an advanced technology. Our team of experts identify each and every product to ensure the best quality and flawless of these products available at suitable rates |
Orifice Flange | Orifice Flange helps to measure the flow of liquids and gases using orifice meters located on the outside diameter of the flanges. The main purpose of the orifice flange identifies the flow rate of either liquid or gas in the pipeline system. |
Spectacle Flange | A spectacle flange is a specialty flange made of two metal discs attached in the middle by a small section of steel. Spectable flanges get their name because they look like a pair of reading glasses, or spectacles. |
Description | Duplex 2205 Flanges Price in China |
ASTM A182 S31803 (2205) Duplex Steel Flange-ASME/ANSI B16.5 | US $ 5.58-5.88 / kg |
Sans B16.5 Wn Duplex Steel 2205 Steel Forged Welded Flange | US $ 0.5-20 / Piece |
Sorf S32205 Duplex Stainless Steel Flanges 2205 Corrosion Resistance | US $ 5.06-6.39 / Piece |
A182 Duplex 2205 Stainless Steel 300lb Flange | US $ 1 / Piece |
Duplex Steel 2205/31803 Material Sorf Red Flange | Min. Order: 10 Pieces |
ANSI B16.5 150lbs Weld Neck Duplex Stainless Steel Duplex 2205 ASME B16.5 1/2" - 24" 150# RF Rtj Lj Flange | US $ 0.2-20 / Piece |
2205 Corrosion-Resistant Duplex Stainless Steel Flange | US $ 1000 / Ton |
Duplex 2205 Stainless Steel RF Flange, Blind Flange, Wn Flange | US $ 5 / Piece |
SABS1123 2205 Slip on Super Duplex Steel Flange | US $ 1 / Piece |
Duplex 2205 Stainless Steel RF Flange, Blind Flange, Wn Flange | US $ 5 / Piece |
Duplex steel S32205 Flange is an alloy of stainless steel commonly used in the automotive industry. The material has excellent corrosion resistance and strength, making it ideal for applications such as exhaust systems, fuel tanks, and brake lines. It also has a high heat resistance, making it suitable for use in engine components exposed to high temperatures. Additionally, duplex steel S32205 Flange can be easily welded and machined, making it a versatile material for use in the automotive industry.
Duplex steel S32205 Flange are exceptionally corrosion-resistant, making them ideal for chemical processing equipment use. This material produces tanks, heat exchangers, and piping systems that transport liquids in acidic environments.
Designers and builders for duplex steel S32205 Flange for several applications in the construction industry. You can find this material in structures such as bridges, tunnels, and even commercial and residential buildings. In addition, designers choose duplex steel to produce railings, facades, and roofs, thanks to its high strength and weather resistance.
Duplex steel S32205 Flange are applied in the transportation industry to design components suitable for harsh environments, such as marine structures and oil and gas pipelines. This unique material is also ideal for producing automobile exhaust and turbocharger systems.
Duplex steel S32205 Flange is a popular choice in the power generation sector. Its outstanding corrosion resistance and strength make it an excellent option for energy utilization systems such as oil rig platforms and wind turbines.
Duplex steel S32205 Flange is also widely used in the oil and gas industry due to its corrosion resistance and strength. The material is often used in pipelines, valves, pumps, and other components exposed to harsh environments. Additionally, duplex steel S32205 Flange can withstand high temperatures and pressures without losing its integrity or performance over time. This makes it an ideal choice in the oil and gas industry, where components must remain reliable even under extreme conditions.
In the food industry, duplex steel S32205 Flange materials are utilized widely in manufacturing machinery and equipment. This steel type has significant corrosion and acidity resistance, meets hygiene requirements, and guarantees contamination-free manufacturing for the food industry.
Duplex steel S32205 Flange is a unique material that has become a staple in manufacturing, particularly in the industrial sectors. These sectors have adopted the metal due to its outstanding corrosion resistance, strength, and weldability. This material has applications in many fields that demand superior strength, flexibility, and resistance to harsh conditions. These various applications include chemical processing equipment, construction, transportation, power generation, and food. With the growing demand and superb performance of Duplex Steel S32205 Flange, its versatility and usage will continue to grow.
