Everything you need to know about Nickel 201 flanges

Views: 2     Author: Wang     Publish Time: 2024-10-11      Origin: Site

wechat sharing button
whatsapp sharing button
linkedin sharing button
pinterest sharing button
facebook sharing button
sharethis sharing button

What are the properties of Nickel 201?

Nickel 201 is a wrought commercially pure Nickel with a maximum carbon level of 0.02%. Lower carbon content also reduces hardness, which makes it ideally suited for spinning and cold forming. This alloy provides highly ductile mechanical properties across a wide temperature range.It provides corrosion resistance in neutral to moderately reducing environments. Nickel 201 is ferromagnetic. It provides high thermal and electrical conductivity in comparison to nickel-base alloys, stainless and low alloy steels. Because of its low carbon content (.02% max.) Nickel 201 may be considered for service above 600 °F (316 °C), where alloy 200 with higher carbon content is not recommended.


Nickel 201 has the same characteristics Nickel 200 but has lower carbon levels. These properties, and its chemical composition, make Nickel alloy 201 fabricatable and highly resistant to corrosive environments. It is highly resistant to corrosion by neutral and alkaline salt solutions, fluorine and chlorine. Nickel alloy 201 also has low corrosion rates in neutral and distilled water. Commercially pure Nickel (Nickel 201), with good mechanical properties and excellent corrosion resistance in many environments. Compared to nickel alloys, Nickel 201 has high electrical and thermal conductivity and good magnetostrictive properties. It also maintains high ductility over a wide range of temperatures.


Nickel 201 consists of a minimum of 99.2% nickel. The high nickel content contributes to its superior corrosion resistance, making it highly resistant to a wide range of corrosive environments, including acids, alkaline solutions, and saltwater. It exhibits excellent resistance to both reducing and oxidizing conditions. The primary applications of Nickel 201 include chemical processing equipment, where its corrosion resistance is highly valued. It is used in the production of electrical connectors, batteries, and electronic components due to its excellent electrical conductivity. In the aerospace industry, Nickel 201 finds application in aircraft components and rocket motor cases.


What is Nickel 201 Flange?

As a Well Known manufacturer and supplier of Nickel Alloy Flanges, JN Alloy is making its way to the top in the national and international market. Our offered ASTM B564 Nickel Alloy Pipe Flanges are used in heat exchangers, pharmaceutical equipment, condensers and power generation etc. These ASME SB 564 Nickel Alloy 201 Flanges are used with a Lap Joint flange,in various indusutrial applications. In valves and pressure opening vessels mostly used Nickel Alloy UNS N02201 Blind Flanges because of highly stressed flanges.contact us.


Nickel Alloy DIN 2.4061 Slip on Flanges are easy to recognise due to their long tapered hub. It is suitable to be used in hostile environments with extreme temperatures. We uses High quality ASTM B564 Nickel Alloy UNS N02201 Weld Neck Flanges which has great thermal stability and offers them at competitive prices to clients as per requirement. We have wide range Nickel Flanges such as Nickel Alloy ASTM B564 200 Flanges, Alloy 200 Orifice Flanges, Nickel Alloy 200 Slip On Flanges, Nickel Alloy 201 Weld Neck Flanges, Nickel 200 Socket Weld Flanges, 201 Nickel Alloy Blind Flanges, Nickel 201 Spectacle Blind Flanges, Alloy 200 Screwed / Threaded Flanges, Alloy 201 Ring Type Joint Flanges (RTJ), Nickel Alloy 200 Reducing Flanges etc.


ASTM B564 Nickel Alloy UNS N02201 Flanges As an acclaimed undertaking of the business, JN Alloy is included in offering an endless cluster of Nickel Alloy 201 Flanges as a maker, exporter, stockiest and supplier to our local and worldwide customers.Contact us for more information on our Nickel 201 flanges, or request a quote today.


Specification List of Nickel 201 Flanges

Specification

Nickel 201 Flanges

ADNOC Approved Manufacturer Of Standards

ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, MSS S44, IS 2062, ISO70051, API, API7S-43, ANSI/ASME B16.5, API7S-15

Temperature Ratings

150 LB To 2500 LB

Face Type Details

Raised Face, Large Tongue & Large Male-Female And Small Male-Female, Groove And Small Tongue Groove, RTJ, Flat Face, Lap-Joint Face.

Forging Materials

Stainless Steel, Alloy Steel, Carbon Steel, Duplex Steel & Super Duplex Steel, Cast Iron, Inconel, Mild Steel, Hastelloy, Copper Nickel, Wrought Iron.

Thickness

NPS ≤ 18

Flanges High Temperature

Above 200° Celsius (400°F) For 150 Class Or Above 400° Celsius (750°F)

JIS Standards

5K, 10K, 40K, 16K 20K 30K, 63K

Our Top Selling Products

Lap Joint, Socket-Weld, Blind, Threaded, Weld Neck, Slip-On

Buy Flanges For Pipe Connection

Power Plants Industry
Food Processing And Manufacturing
Waterworks Systems
Nuclear Power Application
Municipal Pipe Systems
Fossil Fuel Power Plants
Oil And Gas Industry

Type Of Making Format

Plate /Forged/ Threaded

Bore Diameter

NPS ≤ 10

Size Chart

(1/2") To (48")

Manufacturing Process

· Heat Treated/ Machined / Forged


Application Of Nickel 201 Flanges

The application of Nickel 201 flanges is widespread and critical in various industries, playing a fundamental role in the seamless functioning of piping systems. Here are vital applications where Nickel 201 flanges are commonly employed:


1. Oil & Gas Sector

For the pipeline and refinery construction, Nickel 201 flanges are utilized extensively. These make it easier to connect pipes, valves, and other components, with a variety of versions available for both onshore and offshore applications.


2. Chemical Industry

In this industry, transportation of corrosive and hazardous fluids is common. Thus, Nickel 201 flanges are required to secure the connection between pipes and equipment. The ability to select corrosion-resistant materials ensures the system’s integrity.


3. Water Treatment Plants

Nickel 201 flanges are commonly utilized to construct pipelines that transport treated water in this industry. These are versatile and can be customized to meet the individual needs of water treatment operations.


4. Petrochemical Plants

These facilities handling various chemicals and gases benefit from the adaptability and strength of Nickel 201 flanges. The secure connections provided by flanges contribute to these industrial processes’ overall safety and efficiency.


5. Power Generation

Nickel 201 Weld neck flanges are extensively used in power plants to convey high-temperature and pressure fluids. These provide a strong connection, ensuring the integrity of piping systems in power generation plants.


6. Pharmaceutical Industry

Transportation of delicate chemical compounds is frequently involved in pharmaceutical industry manufacturing processes. Nickel 201 flanges, particularly those made of pharmaceutical-grade materials, maintain the pipe system’s integrity and cleanliness.


8. Construction & Building Services

Nickel 201 Flanges are utilised in construction projects and building services to make reliable plumbing and HVAC systems. Nickel 201 Flanges simplify commercial and residential buildings’ installation, maintenance, and repairs.
