Enter Hastelloy X, a superalloy that has become indispensable across various high-stakes industries. Known for its exceptional strength, remarkable resistance to oxidation and carburization, and superior performance under stress, Hastelloy X is the material of choice for demanding applications. In this article, we will dive into the technical intricacies of Hastelloy X sheets and plates, exploring their unique chemical composition and mechanical properties that make them stand out in the world of metallurgy. We will also uncover the diverse industries that rely on this versatile alloy, from aerospace to nuclear power, and how it meets the stringent requirements of each sector. Additionally, you’ll gain insights into the manufacturing processes that enable the production of Hastelloy X, including advanced techniques like additive manufacturing and precise welding methods.
Hastelloy X plate machining can be performed with conventional methods. Carbide tools are preferred, but high-speed steel cutting tools can also be used. Machinability is similar to that of austenitic stainless steels. The alloys is tough and, therefore, requires rigid fixturing, low cutting speeds and ample cutting fluids, either water-base or sulfochlorinated oil. Additionally, finish grinding is recommended when very close tolerances are required.
Similar to other nickel alloys we supply, such as Inconel 625 & Inconel 718, Hastelloy X plate has excellent welding ability, particularly in conjunction with gas-tungsten-arc (GTA), plasma-arc, and electron-beam welding. Generally, parent metal weld filler is used with welding carried out on solution heat treated material. Often post-weld heat treatment is employed to reduce residual weld shrinkage stresses. Strength and ductility are good in the as-welded condition, but a full post-weld solution heat treatment or lower temperature stress relief (1800F min) is often applied to obtain optimum properties (dimensional stability, fatigue life) in weldments.
Hastelloy X plate has very good forming ability when solution heat treated and can be cold formed by most of the common methods including drawing, rolling, bending, spinning, drop hammering, punching and shearing. The solution-treated condition is optimum for cold-forming operations because it provides minimum hardness and maximum ductility. Nevertheless, as a result of Hast X’s toughness and hardenability, relatively high energy levels and frequent intermediate solution treatments are required during severe cold forming operations. When performing simple bending operations on a brake press, Hastelloy X plate seldom requires lubrication. However, when performing severe forming, heavy-duty lubricants such as metallic soaps, chlorinated or sulfochlorinated oils are required. Additionally, land oil, caster oil or sperm oil lubricants are recommended for intermediate forming. Generally, after final cold working, parts should be solution treated to restore the optimum combination of mechanical properties and corrosion resistance.
Hastelloy X plate possesses excellent corrosion and oxidation resistance. It also has good sea water corrosion resistance and thus attractive for marine applications.
Hastelloy X plate wrought products are normally supplied by the mills in the solution heat treated condition, which provides the optimum combination of mechanical properties and corrosion resistance for practically all applications. Hastelloy X plate solution heat treatment consists of exposure to 2150 F followed by rapid cooling. The hold time at 2150 F varies with the section size of the product, size of load and furnace characteristics. A rule of thumb that provides acceptable results for the Hastelloy X plate being treated is to hold for 1 hour per inch of thickness. The cooling rate from 2150 to 1000 F or below should be rapid enough to prevent carbide precipitation, which decreases corrosion resistance and toughness for Hastelloy X sheet products. Rapid air cooling is adequate for this process, however, oil or water quenching is frequently necessary for heavier sections. If surface oxidation can be tolerated, the Hastelloy X plate solution treatment can be carried out in air or in the normal mixture of air and combustion products in gas-fired furnaces. Alternatively, oxidation can be minimized by the use of an exothermic furnace atmosphere or it can be almost entirely prevented by dry hydrogen, dry argon or vacuum atmospheres.
ASTM B575 Plate Specification | MSRR, AMS, BS, ASTM B575/ B575 |
Hastelloy Alloy X Plate Sizes (mm) | 1000 x 2000, 1220 x 2440, 1500 x 3000, 2000 x 2000, 2000 x 4000 |
DIN 2.4665 Plate Thickness | 0.1 to 100 mm Thk |
Hastelloy X Steel Plate Width | 10-2500mm |
Cw2m Hastelloy X Plate Length | 2m, 2.44m, 3m, or as required |
Hastelloy X UNS N06002 Plate Finish | HR, CR, 2B, 2D, BA, NO(8), SATIN |
Alloy X Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Hastelloy X Plate Stock in form of | Rolls, hot-rolled, Blank, Strip, Circle, cold-rolled, descaled, Clad, annealed, sheared, soft-annealed, Shim, Coils, Tread, Sheet, Checker, Rolling, Flat, Flats, Foils, Plate, |
Why choose Hitesh Steel | · EN 10204/3.1B, · Hastelloy Raw Materials Certificate · 100% Radiography Test Report · Third Party Inspection Report, etc · High special strength, high melt point · Excellent corrosive resistance, good thermal resistance · Customer support after-sales service · Huge Stock, Timely delivery · Strict Control from Raw Material to Finished ASTM B575 plate · Free Quote, Inquiry answered within 24 hours |
Hastelloy Alloy X profiling | To provide a full profiling service we use numerous profiling methods including: · Laser Plate Cutting · Plasma Plate Cutting · Oxy-propane Flame Cutting |
Specialized in | · DIN 2.4665 Plates : material 3/16" [5.00 mm] and over in thickness and over 10" [250 mm] in width; · Hastelloy Steel Sheet: material under 3/16" [5.00 mm] in thickness and 24" [600 mm] and over in width; · Cw2m Hastelloy Strip: cold-rolled material under 3/16" [5.00 mm] in thickness and under 24" [600 mm] in width. · ASME SB 575 Clad plate: a composite steel plate made by bonding, etc. |
Hastelloy X plate is widely used in the aerospace industry for its superior strength and corrosion resistance at high temperatures. Key components made from Hastelloy X plate include jet engine parts like combustion chambers, afterburners, transition ducts, combustor cans, spray bars, and flame holders, thanks to its ability to withstand extreme temperatures and oxidative environments. It is also used to make aircraft engine blades, nozzles, rocket thrusters, and other propulsion parts, ensuring reliable performance in tough conditions.
In the petrochemical and chemical processing industries, Hastelloy X plate is essential because it resists oxidation, carburization, and chloride stress corrosion cracking. Components like retorts, muffles, catalyst support grids, furnace baffles, and pyrolysis tubing are often made from Hastelloy X plate, ensuring the longevity and safety of critical processing equipment in harsh environments.
In the nuclear power industry, Hastelloy X plate is used for its stability at high temperatures and corrosion resistance, particularly in making parts for gas-cooled reactors and heat units. The alloy’s ability to maintain mechanical integrity under high thermal stress is crucial for the safe and efficient operation of nuclear power plants. Hastelloy X plate is also used in nuclear fuel element cladding, providing a robust barrier against radiation and chemical attack.
In the automotive sector, Hastelloy X plate is used for high-performance and high-temperature parts like turbochargers, exhaust valves, and other exhaust components, benefiting from its strength and corrosion resistance. The material’s durability under thermal cycling conditions ensures the reliability and efficiency of automotive engines, especially in turbocharged and high-performance vehicles.
Hastelloy X plate also excels in other fields thanks to its exceptional properties. In the medical field, it is used for devices and instruments requiring high strength and corrosion resistance. It is also vital in steam turbine power plants for withstanding high temperatures and corrosive environments. Additionally, Hastelloy X is used in the manufacturing of furnace parts, such as furnace rolls and trays, which must operate at elevated temperatures without significant degradation.
