Views: 3 Author: Shirley Publish Time: 2025-06-05 Origin: Site
Inconel 625 is a nickel-chromium-molybdenum alloy with an addition of niobium that acts with the molybdenum to stiffen the alloy's matrix and thereby provide high strength without a strengthening heat treatment. Inconel 625 resists a wide range of severely corrosive environments and is especially resistant to pitting and crevice corrosion. Alloy 625 Plates, known for their superior oxidation resistance and resistance to pitting, are essential in critical applications. The strength of Alloy 625 Coils can be further enhanced through heat treatment. The high molybdenum content in Inconel 625 sheet makes them highly resistant to pitting and crevice corrosion. Inconel 625 plates are nickel-based and can withstand temperatures ranging from cryogenic extreme freezes to 1000 degrees Celsius/2000 degrees Fahrenheit. ASTM B443 UNS N06625 Plate has a minimum yield strength of 430MPa and a minimum tensile strength of 940MPa due to the nickel chromium framework, molybdenum material, and strong solution strengthening.
Generally, Inconel alloy 625 plate, sheet and strip shall be manufactured in accordance with ASTM B443/ ASME SB443. Designated as UNS N06625, the material has a nominal chemical composition of 60Ni-22Cr-9Mo-3.5Cb, which indicates that it is a nickel-chromium-molybdenum-columbium alloy. The Inconel 625 alloy plate, sheet and strip can be furnished in two grades of different heat-treated conditions: Grade 1 (annealed) – Material is normally employed in service temperatures up to 1100°F (593°C); Grade 2 (solution annealed) – Material is normally employed in service temperatures above 1100°F (593°C) when resistance to creep and rupture is required.
JN Alloy is the leading Inconel 625 plate supplier, offering an extensive range of Alloy 625 Sheets, Plates, and Coils. These products exhibit remarkable Inconel 625 material properties, boasting exceptional resistance to oxidation and corrosion. The strength and durability of Inconel 625 composition are derived from the solid solution properties of refractory metals like molybdenum and columbium within a chromium-nickel matrix, as specified in the Inconel 625 specification. Inconel 625 Plates, available in various sizes and shapes, display outstanding fatigue resistance and are highly weldable. These coils are commonly utilized in nuclear reactors and pollution-control equipment. Moreover, our Inconel 625 Plates meet the demands of diverse industries.
Inconel 625 plate is renowned for its unique combination of mechanical and chemical properties, making it suitable for a wide range of demanding applications.
Inconel 625 plate exhibits exceptional resistance to a variety of corrosive environments. It is particularly effective against pitting and crevice corrosion, as well as cracking caused by exposure to chlorides. This makes it an ideal material for marine applications and environments where exposure to seawater and other aggressive media is common.
The alloy 625 plate maintains high tensile and yield strength across a broad temperature range. In annealed conditions, it has a tensile strength of approximately 930 MPa (135,000 psi) and a yield strength of around 517 MPa (75,000 psi). This high strength is largely due to the presence of nickel, chromium, and molybdenum, with niobium further enhancing its mechanical properties.
Inconel 625 plate with stands extreme temperatures, maintaining its mechanical properties up to 1000°C (2000°F), making it ideal for applications experiencing thermal stress and rapid temperature changes, such as turbine blades and exhaust systems in aerospace applications.
Inconel 625 Chequered Plate | Inconel 625 UNS N06625 Quarto Plate |
ASME SB443 Alloy 625 Clad Plate | ASTM B443 Alloy 625 Tisco Plate |
Inconel UNS N06625 Chequer Plate | ASME SB443 Inconel 625 Tread Plate |
ASTM B443 Alloy 625 Checker Plate | WNR 2.4851 Polished Plate |
ASME SB443 Inconel 625 Plate Mirror Finish | Inconel DIN NR. 2.4851 Chequered Plate |
WNR 2.4851 Plate Brushed Finish | ASME SB443 UNS N06625 Hot Rolled Sheet |
Inconel DIN NR. 2.4851 10mm Plate | ASTM B443 Inconel 625 Cold Rolled Sheet |
ASME SB443 UNS N06625 1/4 Inch Plate | 625 Inconel Perforated Sheet |
Hairline Mirror finish Nickel Alloy 625 Sheet | Inconel 625 Nickel Plate material |
SB 443 Alloy 625 Strip | Inconel 625 Grade 2D Plate |
Inconel Alloy 625 Shim Sheet | ASTM B443 Alloy 625 Coil |
Inconel 625 Din 2.4856 Polished Plate | Alloy 625 Nickel Cold Rolled Plate |
Inconel 625 Nickel Alloy 4mm Thick Plate | 625 Inconel Sheet |
Inconel 625 UNS N06625 Flat Plate | JIS NCF 625 Plate |
SB 443 Inconel 625 Clad Plate | Nickel Alloy 625 Coil |
Inconel Alloy 625 Plate | Alloy 625 Rolling Plate |
Inconel 625 UNS N06625 Hot Rolled Plate | ASTM B443 Alloy 625 Perforated Plate |
Alloy 625 Cold Rolled Plate | UNS N06625 Bbq Plate |
ASTM B443 Alloy 625 Plate 2b Finish | ASME SB443 Alloy 625 Diamond Plate |
UNS N06625 Plate Mill Finish | Inconel UNS N06625 Thin Plate |
ASTM B443 Inconel 625 Custom Cut Plate | Inconel WERKSTOFF NR. 2.4851 Sheet |
625 Inconel Checkered Plate | Inconel 625 Laser Cut Plate |
Inconel WERKSTOFF NR. 2.4851 Embossed Plate | Inconel Alloy 625 Plasma Cutting Plate |
Price of Inconel 625 Plate | ASTM B443 Inconel 625 Plate Price (INR) | Inconel 625 UNS N06625 Plate Price in USD | Alloy 625 Plate Price in UAE Dirham |
NICKEL ALLOY SHEET/PLATE GRADE INCONEL 625 | INR 2,314 | $114.23 | 31.10 UAE Dirham |
625 TRIM INCONEL 625 PLATES | INR 20,168 | $995.61 | 271.07 UAE Dirham |
NICKEL ALLOY INCONEL 625 PLATE AMS 5599 9.53MMX50.4 MMX 50.4MM .375X1.98X1.98 | INR 1,421 | $70.15 | 19.10 UAE Dirham |
NICKEL ALLOY INCONEL 625 PLATE AMS 5599 12.7MMX70 MMX 70 MM.50X2.76X2.76 | INR 3,330 | $44.76 | 164.39 UAE Dirham |
Inconel 625 sheet tolerance up to & under nominal thickness t (mm) | ||||||||||
Width w (mm) | 8.0<t <10.0 | 2.5<t <4.5 | 6.0<t <8.0 | 4.5<t <6.0 | 12.5<t <16.0 | 10.0<t <12.5 | 20.0<t <25.0 | 16.0<t <20.0 | 30<t <40.0 | 25.0<t <30.0 |
1200< w <1500 | 0.35 | 0.20 | 0.30 | 0.25 | 0.80 | 0.38 | 0.90 | 0.80 | 1.4 | 1.0 |
2400< w <2700 | 0.80 | 0.80 | 0.80 | 0.90 | 0.80 | 1.1 | 1.0 | 1.7 | 1.3 | |
1800< w <2100 | 0.40 | 0.20 | 0.36 | 0.30 | 0.80 | 0.45 | 0.90 | 0.80 | 1.5 | 1.1 |
w < 1200 | 0.32 | 0.20 | 0.30 | 0.23 | 0.80 | 0.35 | 0.80 | 0.80 | 1.4 | 1.0 |
2700< w <3000 | 1.0 | 0.90 | 0.80 | 1.0 | 1.0 | 1.3 | 1.1 | 1.8 | 1.4 | |
1500< w <1800 | 0.38 | 0.20 | 0.32 | 0.28 | 0.80 | 0.40 | 0.90 | 0.80 | 1.5 | 1.1 |
2100< w <2400 | 0.80 | 0.80 | 0.80 | 0.80 | 0.80 | 1.0 | 0.90 | 1.5 | 1.1 | |
Inconel 625 sheets and plates are extensively used in the aerospace industry due to their remarkable high-temperature resistance and mechanical strength. These characteristics make Inconel 625 ideal for high-end engine components, exhaust systems, and other critical aerospace parts. The alloy’s ability to withstand extreme temperatures and resist oxidation ensures long service lives under demanding conditions, making it a preferred choice for aerospace applications.
In the chemical processing industry, Inconel 625 sheets and plates is prized for its exceptional corrosion resistance and high strength. Its corrosion resistance ensures equipment longevity and reliability in harsh chemical environments. This makes it ideal for constructing heat exchangers, reactors, and other equipment exposed to aggressive chemicals at elevated temperatures.
Inconel 625 sheets and plates is also widely utilized in marine applications, particularly in turbine and exhaust systems, as well as components that come into direct contact with seawater. Its resistance to saltwater corrosion and high-temperature stability make Inconel 625 ideal for naval and offshore use, where durability and reliability are paramount.
The nuclear industry benefits from Inconel 625 sheets and plates high mechanical strength and resistance to radiation damage. Inconel 625 is used in nuclear reactor cores and components that endure high temperatures and radiation. Its stability and resistance to degradation under such conditions ensure the safety and efficiency of nuclear reactors.
In the paper industry, Inconel 625 sheets and plates high corrosion resistance and temperature endurance make it ideal for equipment like cutting tools and knives. The alloy’s durability enhances production efficiency and ensures high-quality output in the paper production process.
In the power generation sector, Inconel 625 sheets and plates is used in turbine parts, nuclear reactor cores, and other high-temperature applications. The alloy’s mechanical stability and resistance to radiation degradation make it a valuable material for ensuring the longevity and reliability of power generation equipment.
The oil and gas industry relies on Inconel 625 sheets and plates for its resistance to heat, pressure, and harsh chemical environments. The alloy is used in drilling tools, underwater pipelines, and wellhead accessories, where its properties extend the fatigue and corrosion life of these components, ensuring safety and efficiency in oil and gas extraction and processing.
