Views: 7 Author: Shirley Publish Time: 2025-05-19 Origin: Site
Hastelloy C22 provides resistance to general corrosion, pitting, crevice corrosion, intergranular attack, and stress corrosion cracking. Hastelloy C22 can be used for many applications such as marine, power, chemical processing, pollution control, paper processing, and waste disposal industries. Hastelloy C22 contains chromium, molybdenum, tungsten, and iron which makes the alloy resistant to corrosion in stagnant or flowing seawater. The alloy is formed by gas tungsten-arc, gas metal - arc, and shielded metal-arc processes.
The Hastelloy is an improved alloy for use in a range of aggressive media. Hastelloy C22 grade has excellent resistance to pitting and crevice corrosion cracking mostly for the harsh chemicals like chlorides, sulfides and other harsh chemicals. These are practically immune to SCC stress corrosion cracking. Hastelloy C22 Plate has superior weldability so common filler welds are use to join these sheets and plates. These have good thermal stability also good workability against corrosive environment. Offered products come with tolerance and machining alloys. These come in tempered and quenched conditions. ASTM B575 is a standard that applies to Hastelloy C22 plate, sheet, and strips made from low carbon, nickel-based alloys. The Haynes Alloy C22 Shim Stock is one such alloy, which, in addition to being a low carbon metal, includes elements such as nickel, chromium, and molybdenum. The materials used in the ASTM B575 Hastelloy C22 Grade Strip Tape must meet the appropriate chemical composition as well as the mechanical specifications. For example, in terms of mechanical property specifications, the 2.4602 Hastelloy C22 Sheet must meet the ASTM B575 specification, which includes properties such as tensile strength, yield strength, elongation, and Rockwell hardness.
The corrosion resistance properties of the ASME SB575 C22 Hastelloy Coil extends to oxidizing acid chlorides, formic acid, acetic acids, wet chlorine as well as ferric and cupric chlorides. The alloy is also resistant to seawater and brine solutions rendering them perfect for marine applications. The Alloy C22 Plate also thrives well in process based industries. Generally, in process based industries, frequent upset conditions are a common occurrence, and unlike Hastelloy C22 Plate, the use of any other alloy like stainless steel can potentially damage the equipment. We as a manufacturer, exporter and supplier offer a wide range Hastelloy C22 Sheets in China and overseas. Hastelloy C22 Plates (UNS N06022) are used in Scrubbers, Heat exchangers, Reaction vessels, Evaporators and more. Over the years of supplying high quality products we set our delivery unit across the world more than that the logistic services offer on time delivery to the clients. Since our introduction in manufacturing of sheets and plates customers enjoy those in wide range of standards, specifications, dimensions and thickness.
Description | Price list of Hastelloy C22 Plate |
Hastelloy C22 high Nickel Alloy Plate | US $ 47-56 / kg |
Hastelloy C22 Stainless Steel Plate | US $ 2000-3000 / Ton |
Nickel Alloy Hastelloy C22 0.1mm Thickness Strip Coil Foil Steel Plate | US $ 2 / Piece |
Hastelloy C22 Nickel Alloy Plate for Pesticide Production | US $ 20-60 / kg |
Hastelloy C22 (Alloy 22 N06022 2.4602) Steel Plate | US $ 989-1400 / Ton |
Nickel Alloy Hastelloy C22 Plate/Sheet | US $ 1600-2500 / Ton |
Corrosion Resistant Hastelloy C22 Explosive Welding Vessel Steel Plate | US $ 10-50 / Piece |
Hastelloy C22 Alloy 22/2.4602 Stainless Steel Plate | US $ 989-1400 / Ton |
Nickel Alloy Hastelloy C22 Sheet | US $ 20-70 / kg |
C22 Hastelloy Plates | UNS N06022 Rolling Plates |
Din 2.4602 Chequer Plates | Nickel Alloy C22 Tread Plates |
UNS N06022 Hastelloy C22 Cold Rolled Plates | Alloy C22 Bbq Plates |
Alloy C22 Hot Rolled Plates | ASTM B575 Alloy C22 Perforated Plates |
Alloy C22 Hastelloy Clad Plates | UNS N06022 Tisco Plates |
ASTM B575 Alloy C22 Chequered Plates | Alloy C22 Quarto Plates |
Alloy C22 Embossed Plates | C22 alloy Plasma Cutting Plates |
Din 2.4602 Plates Brushed Finish | Hastelloy C22 Superalloy Hot Rolled Sheet |
Alloy Hastelloy C22 Plates Mill Finish | Din 2.4602 Thin Plates |
ASTM B575 Alloy C22 Plates 2b Finish | Alloy C22 Hastelloy Diamond Plates |
Nickel Alloy C22 Plates Mirror Finish | Alloy C22 Chequered Plates |
UNS N06022 Checker Plates | Din 2.4602 Polished Plates |
Alloy C22 Custom Cut Plates | Alloy C22 Sheet |
Alloy C22 10mm Plates | Alloy C22 Cold Rolled Sheet |
C22 Superalloy 1/4 Inch Plates | 2.4602 Perforated Sheet |
2.4602 Checkered Plates | ASTM B575 Alloy C22 Laser Cut Plates |
Hastelloy C22 Plates play a crucial role in industrial settings, especially where high corrosion resistance and mechanical strength are essential. These bars are essential in constructing equipment and structures exposed to aggressive chemical processes, ensuring longevity and reducing maintenance needs. Their robust properties minimize maintenance and prevent costly downtime. This alloy’s durability makes it ideal for chemical processing, pollution control, and the oil and gas industry. It is also used in pharmaceutical and food processing, where preventing corrosion contamination is critical. The reliability of Hastelloy C22 Plates in these diverse applications highlights their vital role in ensuring operational efficiency and safety across various industries.
Hastelloy C22 plates exhibit several key mechanical properties that make them suitable for industrial applications. They have a minimum tensile strength of 100 ksi and a minimum yield strength of 45 ksi at room temperature. These strengths vary with temperature, decreasing as temperature rises. The minimum elongation is 45%, indicating good ductility. Hastelloy C22 plates cannot be hardened by heat treatment and is typically provided in the annealed condition, which involves heating to 2050°F (1121°C) followed by rapid cooling. The alloy also has excellent weldability and resists grain-boundary precipitate formation in the weld heat-affected zone. Its density is 0.314 lbs/in³, and it has a thermal expansion coefficient of approximately 6.9 x 10^-6/°F at room temperature. The elastic modulus decreases with temperature, starting at 29.9 x 10^6 psi at room temperature. These properties, combined with its exceptional corrosion resistance, make Hastelloy C22 plates ideal for use in industries such as chemical processing, pharmaceuticals, and oil & gas.
Hastelloy C22 plates, renowned for their exceptional corrosion resistance and high-temperature durability, find wide-ranging applications across industries. In the chemical processing sector, they are used to fabricate reactors, heat exchangers, and piping systems, effectively withstanding harsh environments involving strong acids like hydrochloric and sulfuric acid, as well as chloride-containing media. The pharmaceutical industry relies on these plates for manufacturing equipment to ensure product purity and resist corrosion from aggressive cleaning agents. In the oil and gas sector, Hastelloy C22 plates are critical for components in offshore platforms and refineries, enduring corrosive seawater, sour gas (containing hydrogen sulfide), and high-pressure conditions. They also play a key role in environmental engineering applications, such as waste treatment facilities and flue gas desulfurization systems, where they combat corrosion from acidic wastewater and corrosive gases. Additionally, in the aerospace and nuclear industries, these plates are utilized in specialized components requiring resistance to extreme temperatures and corrosive atmospheres, underscoring their versatility in demanding technical environments.
