NPS (DN) | Schedule
No | Outside Diameter,
in. (mm) | Wall Thickness
in. (mm) | Plain End
Weight (Mass)
Ib/ft(kg/m) |
1/8(6)
1/8(6)
1/8(6)
1/8(6)
1/8(6) | 5S
10S
40S
80S
160S | 0.405(10.29)
0.405(10.29)
0.405(10.29)
0.405(10.29)
0.405(10.29) | ...[Note(1)]
0.049(1.24)[Note (1)]
0.068(1.73)
0.095(2.41)
0.124(3.15） | ...
0.19(0.28)
0.24(0.37)
0.31(0.47)
0.37(0.55) |
1/4(8)
1/4(8)
1/4(8)
1/4(8)
1/4(8) | 5S
10S
40S
80S
160S | 0.540(13.72)
0.540(13.72)
0.540(13.72)
0.540(13.72)
0.540(13.72) | ... [Note (1)]
0.065(1.65)[Note(1)]
0.088(2.24)
0.119 (3.02)
0.145 (3.68） | ...
0.33(0.49)
0.43(0.63)
0.54(0.80)
0.61(0.91) |
3/8(10)
3/8(10)
3/8(10)
3/8(10)
3/8(10) | 5S
10S
40S
80S
160S | 0.675(17.14)
0.675(17.14)
0.675(17.14)
0.675(17.14)
0.675(17.14) | ... [Note(1)]
0.065(1.65)[Note(1)]
0.091 (2.31)
0.126(3.20)
0.158(4.01) | ...
0.42(0.63)
0.57 (0.84)
0.74(1.10)
0.87(1.30) |
1/2(15)
1/2(15)
1/2(15)
1/2(15)
1/2(15) | 5S
10S
40S
80S
160S | 0.840(21.34)
0.840(21.34)
0.840(21.34)
0.840(21.34)
0.840(21.34) | 0.065(1.65)[Note(1)]
0.083(2.11)[Note(1)]
0.109(2.77)
0.147(3.73）
0.188(4.78） | 0.54(0.80)
0.67(1.00)
0.85(1.27)
1.09(1.62)
1.31(1.95) |
3/4(20)
3/4(20)
3/4(20)
3/4(20)
3/4(20) | 5S
10S
40S
80S
160S | 1.050(26.67)
1.050(26.67
1.050(26.67)
1.050(26.67)
1.050(26.67) | 0.065(1.65)[Note(1)]
0.083(2.11)[Note(1)]
0.113(2.87）
0.154(3.91)
0.219(5.56) | 0.68(1.02)
0.86(1.28）
1.13(1.68)
1.48(2.19)
1.95(2.89) |
1(25)
1(25)
1(25)
1(25)
1(25) | 5S
10S
40S
80S
160S | 1.315(33.40
1.315(33.40)
1.315 (33.40)
1.315(33.40)
1.315(33.40) | 0.065(1.65)[Note(1)]
0.109(2.77)[Note(1)]
0.133 (3.38)
0.179(4.55）
0.250(6.35） | 0.87(1.29）
1.41(2.09）
1.68(2.50)
2.17(3.24）
2.85(4.24） |
1 1/4 (32)
1 1/4 (32)
1 1/4 (32)
1 1/4 (32)
1 1/4 (32) | 5S
10S
40S
80S
160S | 1.660 (42.16)
1.660 (42.16)
1.660 (42.16)
1.660 (42.16)
1.660 (42.16) | 0.065(1.65)[Note(1)]
0.109(2.77)[Note(1)]
0.140(3.56)
0.191(4.85)
0.250(6.35) | 1.11(1.65)
1.81(2.69)
2.27(3.39）
3.00 (4.46)
3.77 (5.61) |
1 1/2 (40)
1 1/2 (40)
1 1/2 (40)
1 1/2 (40)
1 1/2 (40) | 5S
10S
40S
80S
160S | 1.900(48.26)
1.900(48.26)
1.900(48.26)
1.900(48.26)
1.900(48.26) | 0.065(1.65)[Note(1)]
0.109 (2.77)[Note(1)]
0.145(3.68)
0.200(5.08)
0.281(7.14) | 1.28(1.90）
2.09(3.11)
2.72 (4.05)
3.63(5.41)
4.86(7.24) |
2(50)
2(50)
2(50)
2(50)
2(50) | 5S
10S
40S
80S
160S | 2.375(60.32)
2.375(60.32)
2.375(60.32)
2.375(60.32)
2.375(60.32) | 0.065(1.65)[Note(1)]
0.109(2.77)[Note(1)]
0.154(3.91)
0.218(5.54)
0.344(8.74) | 1.61(2.39)
2.64(3.93)
3.66(5.44)
5.03(7.48)
7.47(11.12) |
2 1/2(65)
2 1/2(65)
2 1/2(65)
2 1/2(65)
2 1/2(65) | 5S
10S
40S
80S
160S | 2.875(73.02)
2.875(73.02)
2.875(73.02)
2.875(73.02)
2.875(73.02) | 0.083(2.11)[Note(1)]
0.120(3.05)[Note(1)]
0.203 (5.16)
0.276(7.01)
0.375(9.52) | 2.48(3.69)
3.53(5.26)
5.80(8.64)
7.67(11.41)
10.02(14.91) |
3(80)
3(80)
3(80)
3(80)
3(80) | 5S
10S
40S
80S
160S | 3.500(88.90)
3.500(88.90)
3.500(88.90)
3.500(88.90)
3.500(88.90) | 0.083(2.11)[Note(1)]
0.120(3.05)[Note(1)]
0.216(5.49)
0.300(7.62)
0.438(11.13) | 3.03 (4.52)
4.34(6.46)
7.58(11.29)
10.26(15.27
14.34(21.35) |
3 1/2(90)
3 1/2(90)
3 1/2(90)
3 1/2(90) | 5S
10S
40S
80S | 4.000(101.60)
4.000(101.60) 4.000(101.60)
4.000(101.60) | 0.083(2.11)[Note(1)]
0.120(3.05)[Note(1)]
0.226(5.74)
0.318(8.08) | 3.48(5.18)
4.98(7.41)
9.12(13.57)
12.52(18.64) |
4(100)
4(100)
4(100)
4(100)
4(100) | 5S
10S
40S
80S
160S | 4.500(114.30)
4.500(114.30)
4.500(114.30)
4.500(114.30)
4.500(114.30) | 0.083(2.11)[Note(1)]
0.120(3.05)[Note(1)]
0.237(6.02)
0.337(8.56)
0.531(13.49) | 3.92(5.84)
5.62(8.37)
10.80(16.08)
15.00 (22.32)
22.53(33.54) |
5(125)
5(125)
5(125)
5(125)
5(125) | 5S
10S
40S
80S
160S | 5.563(141.30)
5.563(141.30)
5.563(141.30) 5.563(141.30)
5.563(141.30) | 0.109(2.77)[Note(1)]
0.134(3.40)[Note(1)]
0.258(6.55)
0.375(9.52)
0.625(15.88) | 6.36(9.46)
7.78(11.56)
14.63(21.77)
20.80(30.94)
32.99(49.12) |
6(150)
6(150)
6(150)
6(150)
6(150) | 5S
10S
40S
80S
160S | 6.625(168.28)
6.625(168.28)
6.625(168.28)
6.625(168.28)
6.625(168.28) | 0.109(2.77)[Note(1)]
0.134(3.40)[Note(1)]
0.280(7.11)
0.432(10.97)
0.719(18.26) | 7.59(11.31)
9.30(13.83)
18.99(28.26)
28.60(42.56)
45.39(67.56) |
8(20)
8(200)
8(200)
8(200) | 5S
10S
40S
80S | 8.625(219.08)
8.625(219.08)
8.625(219.08)
8.625(219.08) | 0.109(2.77)[Note(1)]
0.148(3.76)[Note(1)]
0.322(8.18)
0.500(12.70) | 9.92(14.78)
13.41(19.97)
28.58(42.55)
43.43(64.64) |
10(250)
10(250)
10(250)
10(250) | 5S
10S
40S
80S | 10.75(273.0)
10.75(273.0)
10.75(273.0)
10.75(273.0) | 0.134(3.40)[Note(1)]
0.165(4.19)[Note(1)]
0.365(9.27)
0.500(12.70)[Note(2)] | 15.21(22.61)
18.67(27.78)
40.52(60.29)
54.79(81.53) |
12(300)
12(300)
12(300)
12(300) | 5S
10S
40S
80S | 12.75(323.8)
12.75(323.8)
12.75(323.8)
12.75(323.8) | 0.156(3.96)[Note(1)]
0.180(4.57)[Note(1)]
0.375(9.52)[Note(2)]
0.500(12.70)[Note(2)] | 21.00(31.24)
24.19(35.98)
49.61(73.79)
65.48(97.44) |
14(350)
14(350) 14(350)
14(350) | 5S
10S
40S
80S | 14.00(355.6)
14.00(355.6)
14.00(355.6)
14.00(355.6) | 0.156(3.96)[Note(1)]
0.188(4.78)[Notes(1),(2)]
0.375(9.52)[Note(2)]
0.500(12.70)[Note(2)] | 23.09(34.34)
27.76(41.36)
54.62(81.25)
72.16(107.40) |
16(400)
16(400)
16(400)
16(400) | 5S
10S
40S
80S | 16.00(406.4)
16.00(406.4)
16.00(406.4)
16.00(406.4) | 0.165(4.19)[Note(1)]
0.188(4.78)[Notes(1),(2)]
0.375(9.52)[Note(2)]
0.500(12.70)[Note(2)] | 27.93(41.56)
31.78(47.34)
62.64(93.18)
82.85(123.31) |
18(450)
18(450)
18(450)
18(450) | 5S
10S
40S
80S | 18.00(457.2)
18.00(457.2)
18.00(457.2)
18.00(457.2) | 0.165(4.19)[Note(1)]
0.188(4.78)[Notes(1),(2)]
0.375(9.52)[Note(2)]
0.500(12.70)[Note(2)] | 31.46(46.81)
35.80(53.33)
70.65(105.17)
93.54(139.16) |
20(500)
20(500)
20(500)
20(500) | 5S
10S
40S
80S | 20.00(508.0)
20.00(508.0)
20.00(508.0)
20.00(508.0) | 0.188(4.78)[Note(1)]
0.218(5.54)[Notes(1),(2)]
0.375(9.52)[Note(2)]
0.500(12.70)[Note(2)] | 39.82(59.32)
46.10(68.65)
78.67(117.03)
104.23(155.13) |
22(550)
22(550)
22(550)
22(550) | 5S
10S
40S
80S | 22.00(558.8)
22.00(558.8)
22.00(558.8)
22.00(558.8) | 0.188(4.78)[Note(1)]
0.218(5.54)[Notes(1),(2)]
...
... | 43.84(65.31)
50.76(75.59)
...
... |
24(600)
24(600)
24(600)
24(600) | 5S
10S
40S
80S | 24.00(609.6)
24.00(609.6)
24.00(609.6)
24.00(609.6) | 0.218(5.54)[Note(1)
0.250(6.35)[Note(1)]
0.375(9.52)[(Note2)]
0.500(12.70)[Note(2)] | 55.42(82.53)
63.47(94.47)
94.71(140.89)
125.61(186.95) |
30(750)
30(750)
30(750)
30(750) | 5S
10S
40S
80S | 30.00(762.0)
30.00(762.0)
30.00(762.0)
30.00(762.0) | 0.250(6.35)[Note(1)]
0.312(7.92)[Note(1)]
...
... | 79.51(118.34)
99.02(147.29)
...
... |
